Description
Model ML2-JL205 is a premium 304 stainless steel hinge featuring a 54×40mm body and a symmetrical left-right design. Equipped with integrated M6×12mm threaded studs, this hinge allows for a concealed installation by simply securing nuts from inside the door panel—leaving no external mounting marks for a cleaner, more refined appearance. Ideal for enclosures and equipment housings that require both functionality and aesthetics, it is finished with a brushed polish for corrosion resistance and a professional look.
Parameters
| Item | Specification |
|---|---|
| Product Model | ML2-JL205 |
| Overall Dimensions | 54mm × 40mm |
| Thickness | 6mm |
| Material | 304 Stainless Steel |
| Surface Finish | Brushed / Polished |
| Pin Diameter | 11mm |
| Mounting Hole Type | M6 Threaded Studs |
| Stud Size | M6 × 12mm |
| Mounting Hole Spacing | 27mm × 38mm |
| Weight | 0.102 kg |
| Customization | Logo and stud length available |
Features
-
Symmetrical Design: Left and right sides are mirror images, suitable for balanced mounting on door panels or enclosure covers.
-
Concealed Fixing: Installation from the inside with nuts keeps external surfaces smooth and clean.
-
304 Stainless Steel Body: Provides excellent resistance to rust and wear, suitable for demanding industrial conditions.
-
Brushed Finish: Improves both visual appeal and resistance to fingerprinting and corrosion.
-
OEM Support: Customizable stud sizes and logo engraving are available for volume orders.
Applications
-
Industrial control cabinets
-
Sheet metal enclosures
-
Test equipment housings
-
Marine-grade access panels
-
Cleanroom and laboratory doors
Benefits of Multi-Knuckle Hinge Design
The multi-knuckle (multi-leaf) hinge structure used in ML2-JL205 enhances load distribution and rotational stability. Compared to traditional two-knuckle designs, multiple interlocking knuckles reduce stress on the central pin, improve wear resistance over time, and provide smoother, more balanced door movement. This makes it especially suitable for frequent-use doors or heavy access panels in industrial environments.
