Description
The ML2-JL1012-2 stainless steel industrial hinge from IHINGES is designed for heavy-duty sheet metal doors and enclosures that require both strength and a premium finish. With dimensions of 65×65×5.2mm, this hinge offers excellent load-bearing capability, making it suitable for various industrial applications. Manufactured from high-quality 304 stainless steel and finished with a mirror polish, it combines functionality with aesthetics. Each hinge can support up to 40kg of load, and customization is available to meet your specific installation requirements.
Parameter
| Item | Specification |
|---|---|
| Product Name | Stainless Steel Industrial Hinge |
| Model Number | ML2-JL1012-2 |
| Brand Name | IHINGES |
| Material | Stainless Steel 304 |
| Surface Treatment | Mirror Polished |
| Overall Dimensions | 65mm × 65mm × 5.2mm |
| Hinge Thickness | 5.2mm |
| Weight | 0.198kg |
| Load Capacity (per hinge) | Up to 40kg |
| Hole Diameter | 5.6mm |
| Mounting Hole Spacing | 40mm (center-to-center) |
| Customization | Logo, Dimensions, Hole Layout |
Features
-
Heavy-Duty Load Capacity: Each hinge supports up to 40kg, suitable for reinforced sheet metal doors.
-
Compact and Precise: 65mm × 65mm design provides robust support without occupying excess space.
-
High-Grade Material: Made from corrosion-resistant 304 stainless steel for long-term industrial use.
-
Mirror Polished Finish: Enhances appearance and resists surface oxidation.
-
Custom Engineering Available: Dimensions, mounting hole layouts, and logos can be customized to project specifications.
Application
Commonly used in:
-
Sheet metal equipment doors
-
Electrical and control panels
-
Industrial testing equipment enclosures
-
Constant temperature and humidity chambers
-
Customized industrial-grade hardware installations
Advantages of Mirror Polishing
Mirror polishing is a surface treatment that provides a smooth, highly reflective finish to stainless steel products. It not only enhances the appearance, making the hinge look clean and modern, but also improves surface hardness and corrosion resistance. The polished finish is less likely to accumulate dirt or moisture, making it easier to clean and ideal for high-hygiene or visually exposed environments.
